Granny Flat 1
Compact, Comfortable and Full of Possibility
Granny Flat One is a smartly designed two-bedroom layout that makes the most of every square metre. Designed for ultra-narrow spaces, it combines an open plan kitchen, dining and living area with practical inclusions such as a concealed laundry, built-in linen storage and built-in robes to both bedrooms. Despite its compact footprint, the layout feels welcoming, functional and easy to live in.
Whether it's used for extended family, visiting guests or as a rental opportunity, Granny Flat One offers flexibility to suit a range of lifestyles. Built alongside a new McDonald Jones home, it's a practical solution that adds independence, value and versatility to your property.
Note: Granny flats are not offered as a stand-alone build, they are constructed at the same time as your main residence.
Floorplan
Granny Flats
Granny Flat 1
2
1
0
1
1
1
8.6m
House Width:
9m
House Depth:
6.7m
Total:
60m²
Granny Flats
Granny Flat 1
2
1
0
1
1
1
8.6m
House Width:
9m
House Depth:
6.7m
Total:
60m²
Room Dimensions
Kitchen/Dining
3.4m x 4.0m
Lounge
3.2m x 3.3m
Bed 1
3.0m x 3.0m
Bed 2
2.2m x 3.0m
Note: Floor plan will differ slightly with application of different facades. Block widths required differ from area to area, are indicative only and subject to council guidelines and developer requirements. Please check with your Building and Design consultant for details in your area. Total (m²) area includes alfresco or alfresco grande. Non-fixed furniture shown on floor plans, including desks in Study and Study Nooks are indicative only and not included. The sizes of windows and external doors shown may vary from the standard plans due to the new 7 star BASIX requirements effective from October 1, 2023. Please talk to your Building and Design Consultant for more information.
Facades
/
Classic Facade
Note: Images of facades shown are a guide only. Material finishes, dimensions and colours shown are purely an expression of the artist and subject to change depending on availability and design updates. Please refer to our current price list and specifications for façade finishes allowed in published price.
Inclusions
Granny Flat | Kitchen
- StanGranny Flat |dard inclusions
- 1¾ Stylus bowl kitchen sink
- Posh Bristol Flickmixer
- Microwave shelf with powerpoint
- Laminated benchtops including butler's pantry if applicable
- 600mm appliance package with oven, rangehood and electric cooktop
- Pantry with white melamine shelves
- Bulkhead to kitchen
Granny Flat | Internal
- Standard inclusions
- Clipsal switches and GPO throughout
- Wardrobe double doors where shown with melamine shelves
- 67mm half splayed architraves and mouldings
- Electrical as per the standard electrical plan
- Taubmans ‘Endure’ to all internal walls 2 coat system
- Flush panel internal doors with Gainsborough classic knob set
- 90mm cove cornice
- 2400mm nominal ceiling height
- Smoke Detectors as per standard electrical plan wired direct to mains power.
Granny Flat | Bathroom
- Standard Inclusions
- Large selection of ceramic tiles
- GenX cross handle taps
- Base acrylic bath with overflow
- European designed laminated vanities with attractive laminated bench tops
- 1800mm high semi-frameless shower screen
- Frameless mirror above vanity
- Roca Debba rimless close coupled toilet suite
Granny Flat | External
- Standard Inclusions
- SUPALOC steel frame with Bluescope 50 year structural warranty*
- Classic facade included
- Austral Bricks from selected range
- Colorbond roof
- Haier Monoblock Heat Pump 330L 2.2kW
- 365 day fixed price tender
- R4.1 insulation to ceilings and R2.0 insulation to external walls
- Concrete slab engineered designed to M classification
- Superior Kordon termite barrier protection
- Architectural styled aluminum windows as per facade selected
Dual Living | Kitchen
- Already Yours Inclusions
- 1¾ Base Mk3 sink
- Mizu Drift square sink mixer in chrome
- Hettich Sensys soft close hinges to cupboards
- Soft close drawers
- Laminated benchtops including butler's pantry (if applicable)
- 600mm Haier appliance package with under bench oven, rangehood (incl ducting) and electric or 5 burner electric cooktop
- Pantry with white melamine shelves
- Overhead cupboards with bulkhead included
Ask about our 'Added Luxury' Inclusions
Dual Living | Internal
- Already Yours Inclusions
- Clipsal switches and GPO throughout
- Wardrobe double doors where shown with melamine shelves
- 67mm half splayed architraves and mouldings
- Electrical as per the standard electrical plan
- Painted timber handrail and stringers, painted timber posts and round black metal balusters with medium-density fibreboard (MDF) treads and risers suitable for carpet on two storey homes
- Taubmans ‘Endure’ 3-coat system to all internal walls
- 2040mm Hume internal doors with choice of Gainsborough door handles
- 90mm classic cove cornice
- 2400mm nominal ceiling height
- Smoke Detectors as per standard electrical plan wired direct to mains power
Ask about our 'Added Luxury' Inclusions
Dual Living | Bathroom
- Already Yours Inclusions
- Roca Debba rimless close coupled toilet suite
- Mizu Drift chrome tapware and fixtures
- Posh Bristol 7 function rail shower
- Your choice 300x300 or 300x450 floor and wall tiling to all wet areas
- Vanity width polished edge frameless mirror, on 300mm high tiled splashback
- Base acrylic bath with overflow
- Semi-frameless 2000mm high shower screen
- Luxury Polytec or Laminex matt finish to cupboards
- 450mm Roca The Gap semi inset basin
- European designed laminated vanities with attractive laminated benchtops
Ask about our 'Added Luxury' Inclusions
Dual Living | External
- Already Yours Inclusions
- Supaloc steel frame with Bluescope TRUECORE 50 year structural warranty*
- Classic facade included
- Your choice of Austral Bricks across Wilderness or Everyday ranges
- Colorbond roof and sectional overhead garage
- Architectural styled aluminum windows as per facade selected
- Rheem 26 litre continuous flow hot water unit
- McDonald Jones 25 year Transferable Structural Guarantee
- 365 day fixed price tender
- R4.1 insulation to ceilings and R2.0 insulation to external walls including internal wall of garage
- Concrete slab engineered designed to M classification
- Superior Kordon termite barrier protection including installation to all door openings and garage
- Hume Vaucluse entry door
- Modline rain water tank up to 4,990litre to external wall
- Sarking to underside of your roof
Ask about our 'Added Luxury' Inclusions
